DR2086: Steel Rear 70 Degree Flat Mount, No Eyelets, 12 mm

DR2086: Steel Rear 70 Degree Flat Mount, No Eyelets, 12 mm
The right side accommodates an insert that can be purchased separately here or from the Related Products below.

Out of stock

$57.82
Description

Description

This 70 degree dropout assembly has been specifically designed to work with flat mount brake calipers. This assembly consists of three pieces: right and left 4130 steel frame components and a matching 1018 steel caliper mount. The caliper mount must be brazed or welded to the dropout by the builder; locating features are integral, no fixture is needed for location. The brake mount is 10 mm thick and the axle hole is 12 mm.

Important Information

  1. The right side accommodates an insert that can be purchased separately here or from the Related Products below.
  2. Skewers are available at a 23% discount with the purchase of a compatible insert.
  3. Skewer and insert compatibility are only guaranteed when used with a compatible Paragon Machine Works product.
  4. Sorry, no returns on skewers. Please check skewer drawings for measurements before ordering.
  5. We are not able to advise or make recommendations on compatibility with products that are not manufactured by us.
  6. For information on hanger alignment click here.

Item sold as 3 piece assembly.

Photo courtesy of 44 Bikes.

Features

SPECIFICATIONS

Item Number DR2086
Weight/Grams 236
Material Steel
Skewer OD 12 mm
Alloy 4130
STEP File (right click, "save as") DR2086, BK2070
PDF Drawing DR2086, BK2070
