DR2032: Steel 12 mm Low Mount, 48 Degree, Eyelets
$86.36
Out of stock
SKU
DR2032
- Buy 10 for $79.72 each and save 8%
- Buy 25 for $73.06 each and save 15%
- Buy 50 for $66.50 each and save 23%
The right side accommodates a hanger that can be purchased separately from the Related Products below.
Product Details
- Material: 4130 steel
- Application: ISO disc mount
- Use our 160 mm ISO adapter for a clean, integrated brake mount (see Related Products below)
- Angle: 48 degree
- Frame Components:
- Right and left frame frame components:
- Chamfered 45 degrees x 1 mm around the outside profile and window
- The arced seatstay tab can be cut by the builder to accommodate angles up to 75 degrees
- Tabs = 5 mm thick
- Right frame component:
- 9 mm maximum thickness
- Accommodates a hanger that can be purchased separately from Related Products below
- 8 mm thick with the hanger installed
- For information on hanger alignment click here
- Left frame component:
- Integrated ISO disc mount located between the stays
- 12 mm maximum thickness
- Dropout face and caliper mounting holes are 9 mm thick
- Right and left frame frame components:
- Eyelets: Four, M5 x .8
Item sold by pair.
| SKU | DR2032 |
|---|---|
| Weight/Grams | 280 |
| Select Option | 48 Degrees Eyelets |
| Material/Alloy | 4130 Steel |
| STEP File (right click, "save as") | 12 mm Low Mount Disc Dropouts |
| PDF Drawing | 12 mm Low Mount Disc Dropouts |
