B4048: Left Side, Rocker, Flat Mount, 160 Rotor, 12 mm

B4048: Left Side, Rocker, Flat Mount, 160 Rotor, 12 mm

50+ In stock

  • Buy 10 for $21.23 each and save 16%
  • Buy 25 for $19.46 each and save 23%
  • Buy 50 for $17.71 each and save 30%


This is the left side (non-drive) replacement insert for all of our Rocker dropouts and is compatible with the Shimano E-Thru, DT Swiss RWS, and PMW combination head 12 mm skewers. It is made from black anodized 6061 aluminum and is supplied with a 12 mm through hole. The caliper mount is flat mount style for 160 mm rotor disc brake applications.

Important Information

  1. For useful information on adjustable dropouts, including torque values for our bolts, click here.
  2. Choose the appropriate skewer based on the right side insert.
  3. Insert compatibility is only guaranteed when used with a compatible Paragon Machine Works product.
  4. We are not able to advise or make recommendations on compatibility with products that are not manufactured by us.

Item sold individually.



Item Number B4048
Weight/Grams 67
Insert Type 160 Flat Mount
Skewer OD 12 mm
Plating Black Anodization
STEP File (right click, "save as") B4048
PDF Drawing B4048
